The 12V LED driver is a power supply that can be use for all of the Luxello LED numbers. The LED driver has a constant output of 12 VDC with an IP 67 rating.
One single LED driver is sufficient to power up to five numbers of the 5″ and 8″ size.
1.0 A
SKU: LUX-12V-DR1
1.67 A – 20W, 50/60 Hz
SKU: LUX-12V-DR2
12V LED Power Supply
Model: DR-1
Input: 110-265 VAC
Output: 12VDC
1.0 A, 50/60 Hz
Size: 3” X 1 “ x 3/4”
12V LED Power Supply
Model : DR-2
Input: 110-265 VAC
Output: 12VDC
1.67 A – 20W, 50/60 Hz
Size: 6” x 1” x 3/4”
On the product page you will find a drop down menu, select each digit you require and add it to the shopping
cart one number at the time. The quantity gets adjusted in the shopping cart only.
Luxello makes the backlit numbers and letters in six sizes including 3”, 5”, 8”, 10”, 16” and 24” inch. There are also 1 - 2 custom sizes that are available upon request. All the numbers can be ordered in the following metal colors including Brushed Silver, Black, Bronze, Brass and Brushed Red combined with any of the LED color options. You will find most of the colors and sizes listed from the overview page.
https://www.luxello.in/size/modern-backlit-numbers/The numbers require a minimum of 10 - 12 Volt AC or DC for optimum voltage. These are low voltage so you will require a transformer like a doorbell transformer or a 5 Watt LED Driver. A single power supply is enough to illuminated up to 6 numbers. The wires from each number all get connected to the same power supply they do not have any polarity. If you have a battery power pack that can output the required voltage requirements then you can use that as well. LED driver options
https://www.luxello.in/product/led-12v-power-supply/
